HOUSE GUARD – CATEGORY 01 / FR / FR-LSH MULTI STRAND COPPER SINGLE CORE UNSHEATHED CABLES IN VOLTAGE GRADE 450/750 VOLTS. (90MTRS)
Electrolytic grade copper conductor carries specified current without deterioration. Uniform and twin insulation ensures safer protection. Centrally aligned Copper conductor with uniform diameter.
| Nom. Area in sq. mm | No./Dia. of wire | Current Carrying Capacity 2 Cables, Single Phase @ | Current Carrying Capacity 2 Cables, Single Phase @ | Price | Packing |
|---|---|---|---|---|---|
| In Conduit Amps | Unenclosed Amps | ||||
| 0.5 | 16/0.2 mm | 5 | 4 | 603.00 | 30 |
| 0.75 | 24/0.2 mm | 7 | 6 | 850.00 | 20 |
| 1.0 | 14/0.3 mm | 12 | 11 | 1062.00 | 20 |
| 1.5 | 22/0.3 mm | 16 | 13 | 1611.00 | 20 |
| 2.5 | 36/0.3 mm | 22 | 18 | 2590.00 | 14 |
| 4.0 | 56/0.3 mm | 29 | 24 | 3930.00 | 10 |
| 6.0 | 84/0.3 mm | 37 | 31 | 5950.00 | 8 |
- Standard colours available Red, Yellow, Blue, Black & Green,
- Standard Packing 90 mtrs. in carton
- Project packing of 270 mtrs/540 mtrs. are poly wrapped.
